MobSF Integration


note

First time using MobSF? Please refer to the following documentation.

Introduction​

Import your Mobile Security Framework (MobSF) security analysis reports into Conviso Platform. This integration automatically processes Android and iOS application security reports and creates security findings.

Features​

  • Report Import: Import MobSF JSON reports via GraphQL mutation
  • Automatic Processing: Asynchronous processing of security findings
  • Asset Management: Automatically creates or links assets based on app name
  • SBOM Support: Automatically imports Software Bill of Materials (SBOM) data when available
  • Finding Mapping: Maps MobSF findings to Conviso Platform format with proper severity levels
  • Status Tracking: Track import status and processing results
  • Multi-Platform: Supports both Android (APK) and iOS (IPA) applications
  • Severity Mapping: Automatically maps MobSF severity buckets (high, warning, info, secure, hotspot) to Conviso severity levels

Prerequisites​

  • A Conviso Platform account
  • A valid Conviso API Key
  • MobSF JSON report file (generated from MobSF analysis)
  • Access to the target company/scope in Conviso Platform
  • Permission to create or update assets and findings

Setup​

Authentication​

The integration uses GraphQL API authentication. Ensure you have:

  1. A valid Conviso API Key
  2. Proper permissions to access the target company/scope
  3. Asset creation/update permissions (if using automatic asset creation)

GraphQL Endpoint​

The integration uses the Conviso Platform GraphQL API endpoint:

POST /graphql

Configuration​

Required Parameters​

The importMobsf mutation accepts the following parameters:

  • file (required): The MobSF JSON report file (Upload type)
  • asset_id (optional): ID of an existing asset to associate the report with
  • company_id (optional): ID of the company/scope. Required if asset_id is not provided

Asset Configuration​

You can configure the import in two ways:

  • Provide company_id only: The system will use the app_name from your MobSF report to automatically find or create an asset
  • Provide asset_id only: Use a specific asset that you've already created in Conviso Platform
important

When providing only company_id, your MobSF report must contain an app_name field. If app_name is missing, the import will fail.

Quickstart​

1. Generate MobSF Report​

First, analyze your mobile application with MobSF and export the JSON report.

2. Import via GraphQL​

Use the importMobsf mutation to import your report:

mutation ImportMobsf($file: Upload!, $companyId: ID) {
  importMobsf(
    input: {
      file: $file
      company_id: $companyId
    }
  ) {
    controlSyncStatus {
      id
      status
      asset {
        id
        name
      }
    }
    errors
  }
}

3. Check Import Status​

Monitor the import status using the returned status information:

query GetImportStatus($id: ID!) {
  controlSyncStatus(id: $id) {
    id
    status
    externalVulnerabilityCount
    importedVulnerabilityCount
    createdVulnerabilityCount
    successCount
    failureCount
    failureReason
    estimatedDurationInSeconds
  }
}

Usage​

Importing Reports​

Option 1: With Existing Asset​

If you already have an asset created in Conviso Platform:

mutation {
  importMobsf(
    input: {
      file: $file
      asset_id: "123"
    }
  ) {
    controlSyncStatus {
      id
      status
    }
    errors
  }
}

Option 2: With Company ID (Auto-Create Asset)​

If you want the system to find or create an asset based on the app name:

mutation {
  importMobsf(
    input: {
      file: $file
      company_id: "456"
    }
  ) {
    controlSyncStatus {
      id
      status
      asset {
        id
        name
      }
    }
    errors
  }
}
note

When using company_id without asset_id, ensure your MobSF report contains the app_name field. The system will:

  • Search for an existing asset with that name in the company
  • Create a new asset if none exists (requires asset creation permissions)

Report Structure​

The MobSF JSON report should follow this structure:

{
  "app_name": "MyMobileApp",
  "package_name": "com.example.myapp",
  "version_name": "1.0.0",
  "version_code": "1",
  "file_name": "myapp.apk",
  "appsec": {
    "app_name": "MyMobileApp",
    "file_name": "myapp.apk",
    "hash": "abc123...",
    "version_name": "1.0.0",
    "package_name": "com.example.myapp",
    "security_score": 75,
    "high": [
      {
        "title": "Insecure Data Storage",
        "description": "The app stores sensitive data insecurely...",
        "section": "storage"
      }
    ],
    "warning": [
      {
        "title": "Weak Cryptography",
        "description": "The app uses weak cryptographic algorithms...",
        "section": "crypto"
      }
    ],
    "info": [],
    "secure": [],
    "hotspot": []
  },
  "sbom": {
    "components": [
      {
        "name": "library-name",
        "version": "1.2.3"
      }
    ]
  }
}

Severity Buckets​

MobSF organizes findings into severity buckets:

  • high: Critical security issues requiring immediate attention
  • warning: Security concerns that should be addressed
  • info: Informational findings
  • secure: Secure practices detected
  • hotspot: Security hotspots identified

The integration automatically maps these to Conviso Platform severity levels.

SBOM Import​

If your MobSF report contains SBOM (Software Bill of Materials) data in the sbom field, it will be automatically imported using the Sbom::ImporterService. The SBOM import runs before the security findings import.

API Endpoints​

The integration provides the following GraphQL mutation:

GraphQL Mutation: importMobsf​

Arguments​

  • file (required): The MobSF JSON report file (Upload type)
  • asset_id (optional): ID of an existing asset to associate the report with
  • company_id (optional): ID of the company/scope. Required if asset_id is not provided

Response Fields​

  • controlSyncStatus: Status tracking object with the following fields:
    • id: Status record ID
    • status: Current status (pending, succeeded, failed)
    • externalVulnerabilityCount: Total findings in the report
    • importedVulnerabilityCount: Successfully imported findings
    • createdVulnerabilityCount: New findings created
    • successCount: Number of successful imports
    • failureCount: Number of failed imports
    • failureReason: Error message if status is failed
    • estimatedDurationInSeconds: Processing duration
  • errors: Array of error messages (empty if successful)

Error Types​

  • AssetNotFoundError: Asset not found or doesn't belong to the company
  • AppNameRequiredError: app_name is required when using company_id without asset_id
  • InvalidInputError: Invalid input parameters or JSON format

Examples​

cURL Example​

curl -X POST https://api.convisoappsec.com/graphql \
  -H "Authorization: Bearer YOUR_API_KEY" \
  -H "Content-Type: multipart/form-data" \
  -F "operations={\"query\":\"mutation($file: Upload!) { importMobsf(input: {file: $file, company_id: \\\"123\\\"}) { controlSyncStatus { id status } errors } }\",\"variables\":{\"file\":null}}" \
  -F "map={\"0\":[\"variables.file\"]}" \
  -F "0=@mobsf_report.json"

JavaScript/TypeScript Example​

import { gql } from '@apollo/client';

const IMPORT_MOBSF = gql`
  mutation ImportMobsf($file: Upload!, $companyId: ID) {
    importMobsf(
      input: {
        file: $file
        company_id: $companyId
      }
    ) {
      controlSyncStatus {
        id
        status
        asset {
          id
          name
        }
      }
      errors
    }
  }
`;

// Usage with Apollo Client
const [importMobsf] = useMutation(IMPORT_MOBSF);

const handleImport = async (file, companyId) => {
  try {
    const result = await importMobsf({
      variables: {
        file,
        companyId
      }
    });

    console.log('Status:', result.data.importMobsf.controlSyncStatus);
  } catch (error) {
    console.error('Import failed:', error);
  }
};

Troubleshooting​

Common Issues​

"You need to provide the asset_id or company_id"​

Solution: Provide at least one of asset_id or company_id in the mutation input.

"App name is required when company_id is provided without asset_id"​

Solution: Ensure your MobSF JSON report contains the app_name field at the root level or within the appsec object.

"User does not have access to this asset"​

Solution: Verify that:

  • The user has proper permissions to access the asset
  • The asset belongs to the specified company
  • The user has the necessary role/permissions in Conviso Platform

"Invalid JSON file"​

Solution: Ensure your MobSF report is valid JSON. Validate it using a JSON validator before importing.

"Asset not found"​

Solution:

  • Verify the asset_id is correct
  • If using company_id only, ensure the app_name in the report matches an existing asset name, or ensure you have permissions to create new assets

Status Monitoring​

Monitor the import progress by querying the import status:

query {
  controlSyncStatus(id: "status_id") {
    status
    externalVulnerabilityCount
    importedVulnerabilityCount
    createdVulnerabilityCount
    failureCount
    failureReason
  }
}

Status values:

  • pending: Import is being processed
  • succeeded: Import completed successfully
  • failed: Import failed (check failureReason for details)

Best Practices​

  1. Validate JSON Before Import: Always validate your MobSF JSON report before importing to catch format errors early
  2. Monitor Import Status: Use the returned controlSyncStatus ID to monitor the import progress
  3. Handle Errors Gracefully: Check the errors array in the response and handle errors appropriately
  4. Use Asset IDs When Possible: If you know the asset ID, use it directly for faster processing
  5. Batch Processing: For multiple reports, process them sequentially and monitor each import status
  6. SBOM Data: Include SBOM data in your MobSF reports when available for comprehensive component tracking

Support​

If you have any questions or need help using the MobSF integration, please don't hesitate to contact our support team.
